Product Model No. : LK WASH 46 – 60
Façade Lighting breathes life into unique facades & architecture in private or public spaces. it can also be used to add an artistic feel to the exteriors with shadows, also use up-lighting for pillars and columns to add a simple contrast or to accentuate the object for making it the centre of attraction
Electrical & Power:
Power Consumption : 50W
Input Power : DC 24V
Optical Arrangement:
Beam Angle : 25°
Optional Beam Angle : 15° , 45°
Field Angle : 32°
Lamp Source:
LED Source : SMD Based
Colour Temperature : 3000K
CRI : > 80
Lumens/W : > 90
Net Luminous Flux : 5500
No of LED’s : 24 No’s
LED Hours Burning life : 50,000
Control & Others:
Control Option : On / Off
Working Temperature : +55° ~ -30°
SDCM : < 5
Power Factor (Min) : 0.9
Driver/power unit : External Power Supply
Physical & Construction:
Dimension : 320 x 240 x75mm
Ingress Protection : IP66 Rated
Body Housing : Aluminium Die Casted
Body Colour : Black / Grey / Custom
Mounting Type : Yoke Mount
Impact Resistance : IK08
Cooling : Passive Cooling System
Protection Class : III Class
Light Distribution chart
Chromaticity Report
Lux level distribution (25°)
