OverView





200W Profile 14 deg

Product Model No. : LK PRO 214 T/D

High Quality Superior Output Long through professional ellipsoidal 200W LED Profile Spot light 14° beam angle with sharp edge high quality optical lens system suitable for special illumination effects for Auditorium stages, TV production Studios Event Stages and multipurpose venues.

Technical Specifications:

Electrical & Power:
- Power Consumption : 210W
- Input Voltage : AC 100V ~ 240V, 50Hz

Optical Arrangement:
- Beam Angle 14°

Lamp Source:
- LED COB Based Source 3200K
- Colour Rendering Index 95+
- Tel. Lighting Consistency Index 95+
- R9 Value 90+
- 50,000 Burning Hours

Physical & Construction:
- Dimension 300 x 700 x 310mm
- Weight 6 kg/ 13.2 lbs
- DmX 5 Pin In and Out
- Power Loop In and Out
- Ingress Protection IP20
- Plastic Moulded Body
- Manually adjustable yoke Mount
- Black/White Powder coated finish
- LCD Easy View Display

Control:
- DmX 512 Through 5 Pin XLR
- 1/3 Channel DmX Control
- DMX/RDM/Auto Run/Master Slave & Manual
- 0% to 100% Dimming
- Manual focus with 4 beam shaping cutters

Others:
- Working Temperature +40° ~ -30°
- Strobe option adjustable 1 ~ 25 times/Sec
- 4 Kinds of Dimming Curves
